Maks. Memori : 64GB
USB :
- AMD Ryzen™ 2nd Generation/ Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ Ryzen™ 1st Generation/ 7th Generation A-Series/ Athlon™ X4 Processors : 4 x USB 3.1 Gen 1 port(s) (4 at back panel, blue, Type-A)
- AMD X370 chipset : 1 x USB 3.1 Gen 2 front panel connector port(s)
- AMD X370 chipset : 4 x USB 3.0 port(s) (2 at back panel, blue, Type-A + USB Type-CTM, 2 at mid-board)
- AMD X370 chipset : 4 x USB 2.0 port(s) (4 at mid-board)
- ASMedia® USB 3.1 Gen 2 controller : 2 x USB 3.1 port(s) (2 at back panel, teal blue, Type-A)
Audio : Realtek® S1220A 8-Channel High Definition Audio CODEC
Kesesuaian RAID : RAID 0, 1, 10
Kesesuaian Memori : DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
External I/O :
- 1 x PS/2 keyboard/mouse combo port(s)
- 1 x DisplayPort
- 1 x HDMI
- 1 x LAN (RJ45) port(s)
- 2 x USB 3.1 Gen 2 (teal blue)Type-A,
- 1 x USB 3.1 Gen 1 USB Type-CTM
- 5 x USB 3.1 Gen 1
- 1 x Optical S/PDIF out
- 5 x Audio jack(s)
Expansion Slots :
- AMD Ryzen™ 2nd Generation/ Ryzen™ 1st Generation Processors : 2 x PCIe 3.0/2.0 x16 (x16 or dual x8)
- AMD Ryzen™ with Radeon™ Vega Graphics /7th Generation A-Series/Athlon X4 Processors : 1 x PCIe 3.0/2.0 x16 (x8 mode)
- AMD Athlon™ with Radeon™ Vega Graphics Processors : 1 x PCIe 3.0/2.0 x16 (x4 mode)
- AMD X370 chipset : 1 x PCIe 2.0 x16 (max at x4 mode) *2; 3 x PCIe 2.0 x1
Internal I/O :
- 1 x Aura RGB Strip Header
- 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
- 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode)
- 8 x SATA 6Gb/s connector(s)
- 1 x CPU Fan connector(s) (1 x 4 -pin)
- 1 x CPU OPT Fan connector(s) (1 x 4 -pin)
- 2 x Chassis Fan connector(s) (2 x 4 -pin)
- 1 x AIO_PUMP connector (1 x 4 -pin)
- 1 x W_PUMP+ connector (1 x 4 -pin)
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin ATX 12V Power connector(s)
- 1 x Front panel audio connector(s) (AAFP)
- 1 x System panel(s) (Q-Connector) (Chassis intrusion header is inbuilt)
- 1 x Clear CMOS jumper(s)
- 1 x 14-1 pin TPM connector
- 1 x COM port header
- 1 x USB 3.1 Gen 2 front panel connector
Lain-lain
Special Features : 5-Way Optimization by Dual Intelligent Processors 5, ASUS 5X Protection III, TPU, EPU, AURA, ASUS Exclusive, ASUS EZ DIY, ASUS Q-Design, Overclocking Protection, Turbo App
Multi-GPU Support : Supports NVIDIA® 2-Way SLI™ Technology *1; Supports AMD CrossFireX™ Technology
Operating System : Windows® 10 64-bit
CPU Socket : AM4
Kesesuaian Prosesor : Supports AMD® RYZEN series processors and 7th Gen A-series/ Athlon™ Processor for Socket AM4
LAN : Intel® I211-AT, 1 x Gigabit LAN Controller
Onboard VGA : Integrated Graphics in the AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics/ 7th Generation A-Series APU
Multi-VGA output support : HDMI/DisplayPort ports
BIOS : 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information
DIMM Sockets : 4 x DIMM
Form Factor : ATX Form Factor
