Maks. Memori : 64GB
USB :
- 3 x USB 3.1 Gen 1 port(s) (3 at back panel)
- 1 x USB 3.1 Gen 2 front panel connector port(s)
- 5 x USB 3.1 Gen 1 port(s) (1 at back panel, 4 at mid-board)
- 1 x USB 3.1 Gen 2 port(s) (USB Type-C, 1 at back panel, )
- 3 x USB 3.1 Gen 2 port(s) (Type-A)
- 6 x USB 2.0 port(s) (4 at back panel, 2 at mid-board)
Audio :
- Realtek S1220A 8-Channel High Definition Audio CODEC
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
- EMI protection cover to prevent electrical noise to affect the amplifier quality
- DTS Headphone:X
- DTS Connect
- Optical S/PDIF out port(s) at back panel
- Unique de-pop circuit: Reduces start-up popping noise to audio outputs
- Supports : Front Panel Jack-retasking, Multi-streaming, Jack-detection
- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers Separate layer for left and right track, ensuring both sound deliver equal quality
- Impedance sense for front and rear headphone outputs
Kesesuaian RAID : 0, 1, 5, 10
Kesesuaian Memori : 4 x DIMM, Max. 64GB, DDR4 2666/2400/3600(O.C.)/4000(O.C.)/4133(O.C.)/2133 MHz Un-buffered, Non-ECC Memory , 8 x DIMM, Max. 128GB, DDR4 4000(O.C.)/4133(O.C.)/2133/2666/3600(O.C.)/2400 MHz Non-ECC, Un-buffered Memory
External I/O :
- 4 x USB 3.1 Gen 1
- 1 x USB BIOS Flashback Button(s)
- 1 x USB 3.1 Gen 2 USB Type-C
- 1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac+ WiGig 802.11ad and Bluetooth v4.1)
- 3 x USB 3.1 Gen 2 Type-A
- 1 x Optical S/PDIF out
- 4 x USB 2.0 (one port can be switched to USB BIOS Flashback)
- 5 x Audio jack(s)
- 2 x LAN (RJ45) port(s)
Expansion Slots :
- 2 x PCIe 3.0/2.0 x16 (max at x4 mode)
- 2 x PCIe 3.0/2.0 x1
- 3 x PCIe 3.0/2.0 x16 (x16, x16/x16, x16/x16/x8)
- 2 x PCIe 3.0/2.0 x16 (x16 or dual x8)
- 2 x PCIe 3.0/2.0 x16 (max at x2 mode)
- 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
- 2 x PCIe 3.0/2.0 x16 (x16, x16/x8)
Wireless LAN : Wi-Fi 802.11 a/b/g/n/ac
Internal I/O :
- 1 x Aura Addressable Strip Header(s)
- 1 x USB 3.1 Gen 2 front panel connector
- 1 x Clear CMOS button(s)
- 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
- 1 x System panel(s) (Chassis intrusion header is inbuilt) (Q-Connector)
- 1 x 4-pin ATX 12V Power connector(s)
- 1 x Power-on button(s)
- 2 x USB 3.1 Gen 1 connector(s) support(s) additional 4 USB 3.1 Gen 1 port(s)
- 1 x CPU_OV jumper
- 1 x 24-pin EATX Power connector(s)
- 1 x VROC_HW_Key
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
- 1 x AAFP connector
- 1 x Thermal sensor connector(s)
- 1 x 8-pin ATX 12V Power connector(s)
- 1 x MemOK! button(s)
- 2 x Chassis Fan connector(s)
- 1 x U.2 connector
- 1 x CPU OPT Fan connector(s)
- 1 x AIO_PUMP connector
- 1 x M.2_FAN connector
- 1 x Thunderbolt header(s)
- 1 x W_PUMP+ connector
- 1 x EZ XMP switch
- 7 x SATA 6Gb/s connector(s)
- 1 x Reset button(s)
- 1 x Aura RGB Strip Header
- 1 x CPU Fan connector(s)
- 1 x 5-pin EXT_FAN(Extension Fan) connector
Lain-lain : Bluetooth V4.1
CPU Socket : Socket 2066
LAN :
- ASUS LAN Guard
- Dual Gigabit LAN controllers- 802.3az Energy Efficient Ethernet (EEE) appliance
- ASUS Turbo LAN Utility
- Intel® I219V, featuring Turbo LAN, 1 x Gigabit LAN Controller(s)
- 1 x Gigabit LAN, Intel® I211-AT, featuring Turbo LAN
Onboard VGA :
- Supports NVIDIA® 2-Way SLI™ Technology
- Supports AMD Quad-GPU CrossFireX™ Technology
- Supports NVIDIA® 3-Way SLI™ Technology
- Supports AMD 3-Way CrossFireX™ Technology
- Supports NVIDIA® Quad-GPU SLI™ Technology
BIOS :
- 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS
- ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information
DIMM Sockets : 4 x DIMM
Form Factor : ATX Form Factor
Serial ATA Controller :
- 1 x M.2 x4 Socket 3
- 7 x SATA 6Gb/s port(s)
- 1 x U.2 port
