Maks. Memori : 64GB
USB :
- 1 x USB 3.1 front panel connector port(s)
- 2 x USB 3.1 Gen 2 port(s) (2 at back panel, )
- 6 x USB port(s) (4 at back panel)
- 2 x USB port(s) (2 at back panel)
- 4 x USB 2.0 port(s)
Audio :
- ROG SupremeFX 8-Channel High Definition Audio CODEC S1220
- Impedance sense for front and rear headphone outputs
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- High quality 113 dB SNR stereo playback output and 110 dB SNR recording input
- SupremeFX Shielding Technology
- ESS ES9023P
- Supports up to 32-Bit/192kHz playback
- LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path
- Sonic Radar III
- Sonic Studio III
Kesesuaian RAID : 0, 1, 5, 10
Kesesuaian Memori : 4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3733(O.C.)/3600(O.C.)/3500(O.C.)/3466(O.C.)/3400(O.C.)/2666(O.C.)/2400(O.C.) MHz Memory, Dual Channel Memory Architecture, Hyper DIMM support is subject to the physical characteristics of individual CPUs
External I/O :
- 1 x DisplayPort
- 1 x HDMI
- 1 x LAN (RJ45) port(s)
- 2 x USB 3.1 Gen 2 ()Type-A + USB Type-C
- 6 x USB 3.1 Gen 1 (blue)
- 1 x Optical S/PDIF out
- 1 x Clear CMOS button(s)
- 1 x USB BIOS Flashback Button(s)
- 5 x LED-illuminated audio jacks
Expansion Slots :
- 2 x PCIe 3.0/2.0 x16 (Single at x16, dual at x8/x8)
- 1 x PCIe 3.0/2.0 x16
- 1 x PCIe 3.0 x4
Wireless LAN : Wi-Fi 802.11 a/b/g/n/ac
Internal I/O :
- 1 x AAFP connector
- 2 x Aura RGB Strip Headers
- 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
- 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)
- 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
- 1 x TPM connector(s)
- 8 x SATA 6Gb/s connector(s)
- 2 x Chassis Fan connector(s)
- 2 x W_PUMP+ connector
- 1 x 24-pin EATX Power connector(s)
- 1 x 8-pin ATX 12V Power connector(s)
- 1 x 4-pin ATX 12V Power connector(s)
- 1 x 4-pin EZ_PLUG Power connector(s)
- 1 x Front panel audio connector(s) (AAFP)
- 1 x System panel(s) (Q-Connector)
- 1 x Slow Mode switch(es)
- 1 x Thermal sensor connector(s)
- 1 x EZ Plug connector(s) (4-pin Molex power connector)
- 1 x Power-on button(s)
- 1 x Reset button(s)
- 1 x BIOS Switch button(s)
- 1 x Clear CMOS button(s)
- 1 x 5-pin EXT_FAN(Extension Fan) connector
- 1 x USB BIOS Flashback button(s)
- 1 x LN2 Mode jumper(s)
- 1 x ROG extension (ROG_EXT) header(s)
- 1 x Safe Boot button
- 1 x ReTry button
- 1 x T_Sensor Connector
- 2 x W_Pump+ Header
- 1 x EXT_Fan header
- 1 x W_IN header
- 1 x W_OUT header
- 1 x W_FLOW header
- 1 x USB 3.1 Gen 2 front panel connector
- 1 x MemOK! Button
- 1 x RSVD Switch
- 1 x 9 pin Monoblock sensor
- 8 x Radiator Fan Headers
Lain-lain : Bluetooth V4.1
CPU Socket : LGA1151
Kesesuaian Prosesor : Intel® Socket 1151 for 7th/6th Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
LAN :
- Intel® I219V
- Anti-surge LANGuard
- ROG GameFirst IV
Onboard VGA :
- Integrated Graphics Processor- Intel® HD Graphics support
- Multi-VGA output support : HDMI/DisplayPort 1.2 ports
- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz
- Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz
- Maximum shared memory of 1024 MB
BIOS : 2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, F9 Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information
DIMM Sockets : 4 x DIMM
Form Factor : Extended ATX
Serial ATA Controller :
- 1 x M.2 Socket 3
- Supports Intel Smart Response Technolog
