DIMM Sockets : 2 x DDR4 DIMM Slots
CPU Socket : LGA1151
Internal I/O :
- 1 x USB 3.0 interface Scalable 2-group external USB 3.0 interface
- 1 x AAFP front audio connector
- 1 x USB 2.0 interface expandable 2-group external USB 2.0 interface
- 4 x SATA 6Gb / s device connection socket
- 1 x TPM connector
- 1 x CPU fan power slot
- 1 x chassis fan connector
- 1 x M.2 slot 3 with M key for 2242/2260/2280 type storage (PCIE mode only)
- 1 x 24-pin EATX board power supply Slot
- 1 x 8-pin ATX 12V board power slot
- 1 x system panel connector
- 1 x clear CMOS jumper
Maks. Memori : 32GB
USB :
- 6 X USB 3.0 / 2.0 ports (four in the rear panel, and two center located on the motherboard), two overvoltage USB interface supports
- 6 X USB 2.0 / 1.1 ports (4 on the rear panel, 2 in the center of the motherboard), 2 ports support USB overvoltage protection
Onboard VGA :
- Supports Intel ® HD integrated graphics
- Supports DVI-D output: display resolution up to 1920 x 1200 @ 60 Hz
- Support for VGA output: DVI-D interfaces
- Shared memory up to: 1024 MB
- Supports Intel® Quick Sync Video, Clear Video HD Technology
External I/O :
- 1 x PS / 2 mouse and keyboard interface
- 1 x DVI-D connector
- 1 x LAN (RJ45) connector
- 4 x USB 3.1 Gen 1 connector
- 4 x USB 2.0 interface
- 3 x audio jack
Expansion Slots :
- 1 x PCIe 3.0 x4 (x4 mode)
- 1 x PCIe 3.0 / 2.0 x16 expansion card slot (x16 mode)
- 1 x PCIe 3.0 / 2.0 x1 expansion card slot
